HiLook PTZ-N2D200M-DE/12(2.8/8mm) - PTZ

Camera

Image Sensor

[Bullet channel]



1/2.9 Progressive Scan CMOS



[PTZ channel]



1/2.9 Progressive Scan CMOS"



Min. Illumination

[Bullet channel]



Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR



[PTZ channel]



Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0.01 Lux @ (F2.0, AGC ON), 0 lux with IR



Shutter Speed

1 s to 1/30,000 s

Slow Shutter

Yes

Day & Night

ICR

Max. Resolution

[Bullet channel] 1920 × 1080, [PTZ channel] 1920 × 1080

Lens

Focal Length

[Panoramic channel] 2.8 mm, [PTZ channel] 8 mm

FOV

[Panoramic channel]



horizontal field of view: 105°, vertical field of view: 58°, diagonal field of view: 123°,



[PTZ channel]



horizontal field of view: 40°, vertical field of view: 22°, diagonal field of view: 46°



Aperture

[Bullet channel] F2.0, [PTZ channel] F2.0

Illuminator

Supplement Light Type

[Bullet channel] Hybrid (IR and White Light), [PTZ channel] Hybrid (IR and White Light)

Supplement Light Range

[Bullet channel]: up to 30 m, [PTZ channel]: up to 30 m

Smart Supplement Light

Yes

PTZ

Movement Range (Pan)

[Panoramic channel] 0° to 355°, [PTZ channel] 0° to 345°

Movement Range (Tilt)

[Bullet channel] 7° to 17° (manually adjust), [PTZ channel] 0° to 80°

Pan Speed

Pan speed: configurable from 4° to 25°/s, preset speed: 25°/s

Tilt Speed

Tilt speed: configurable from 4° to 20°/s, preset speed 20°/s

Presets

300

Power-off Memory

Yes

Video

Main Stream

[Bullet channel]



50 Hz: 25 fps (1920 × 1080, 1280 × 720)



60 Hz: 30 fps (1920 × 1080, 1280 × 720)



[PTZ channel]



50 Hz: 25 fps (1920 × 1080, 1280 × 720)



60 Hz: 30 fps (1920 × 1080, 1280 × 720)



Sub-Stream

[Bullet channel]



50 Hz: 25 fps (640 × 480, 640 × 360)



60 Hz: 30 fps (640 × 480, 640 × 360)



[PTZ channel]



50 Hz: 25 fps (640 × 480, 640 × 360)



60 Hz: 30 fps (640 × 480, 640 × 360)



Scalable Video Coding (SVC)

Yes

Region of Interest (ROI)

1 fixed region for main stream

Video Compression

Main stream: H.265/H.264/Smart264/Smart265,



Sub-stream: H.265/H.264/MJPEG



Video Bit Rate

32 Kbps to 4 Mbps

H.264 Type

Baseline profile,Main profile,High profile
