Ubiquiti UniFi managed 1.5kVA rackmount uninterruptible powe

UniFi managed 1.5kVA rackmount uninterruptible power supply with 4 backup and 4 surge outlets, a field replaceable battery, 216Wh, half load (500W) runtime of 8 minutes. Supports Graceful Shutdown for UNVR and UNAS, NUT compatibility for 3-party devices.



Technical Specifications

Mechanical

Dimensions

442.4 x 300 x 87.4 mm

(17.4 x 11.8 x 3.4")

Weight

13.7 kg (30.2 lb)

Enclosure Material

Galvanized steel

Form Factor

Rack mount (2U)

Weatherproofing

IP20

Hardware

Management

Ethernet

Networking Interface

(1) 100/10 MbE port for network connection

(2) GbE ports for surge in/out

Power

(1) OVC II AC in: C14 socket

(4) Battery backup/surge protection: C13

(4) Surge protection: C13

Capacity

1,500VA/1,000W

Type

Line interactive

Input Voltage Range

170—280V AC

Power Method

(1) TN system, 220—240V AC, 10A Max., 50/60 Hz

Nominal Input Voltage

230V AC

Output Voltage

220—240V AC

Nominal Output Voltage

230V AC

Frequency Range

AC mode: 50/60 Hz ±5 Hz (Auto sensing)

Battery mode: 50 Hz ±1 Hz

AC Voltage Regulation

±10% (Battery mode)

Transfer Time

6 ms typical; 10 ms max. (Battery mode)

Wave Form

Simulated sine wave (Battery mode)

Battery Type

(2) Lead Acid 12V, 9Ah

Runtime

Full load: 2.3 min

Half load: 8 min

Battery Charging Time

6-8 hours recovery to 90% capacity

Overload at On-Line Mode

110% 5 min go to fault

120% go to fault immediately

Overload at Battery Mode

110% shutdown in 5 sec

120% shutdown immediately

Short Circuit Protection at On-Line Mode

Breaker, 250V AC, 10A

Output Short-Circuit Current

Ipeak 444.0A

Irms 223.1A

Buttons

(1) Power

(1) Factory reset

LEDs

Status

Off: device not turned on

Flashing white: initializing / factory default

Steady white: waiting for adoption

Steady blue: device adoption and working

Flashing blue: battery mode

Alternating white/blue: firmware upgrading

Rapid flashing blue: locate

Steady red: warning

Flashing red: low battery

Operating Altitude

3,000 m (1.9 mi)

Operating Environment

Pollution Degree 2

Ambient Storage Temperature

-20 to 50° C (-4 to 122° F)

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

0 to 95% noncondensing

Certifications

CE, IEC 62040-1



Compatibility:

USW-Ultra-210W

,

USW-Pro-Max-16

,

USW-Pro-Max-16-PoE

,

USW-Pro-Max-48

,

USW-48-POE

,

USW-Pro-48

,

USW-Pro-HD-24-PoE

,

UDM-SE

,

USW-Aggregation

,

USW-Flex-2.5G-8

,

USW-Pro-24

,

USW-Pro-XG-10-PoE

,

USW-WAN

,

USW-Pro-Aggregation

,

USW-Pro-8-PoE

,

USW-Pro-XG-48

,

UDM-Pro-Max

,

UXG-Pro

,

USW-24-POE

,

UCG-Fiber

,

UX

,

USW-Flex-2.5G-5

,

USW-Pro-Max-48-PoE

,

UNVR-Pro

,

USW-Pro-Max-24-PoE

,

USW-Flex-Mini

,

USW-Flex-Mini-3

,

USW-Flex-Mini-5

,

USW-Pro-24-POE

,

USW-Pro-XG-24

,

UDR7

,

UDR

,

USW-Flex-XG

,

USW-Pro-HD-24

,

USW-Pro-48-POE

,

USW-Lite-8-POE

,

UNVR

,

USW-48

,

UDM

,

UDM-Pro

,

USW-Enterprise-24-PoE

,

USW-Flex-Utility

,

USW-16-POE

,

USW-Pro-XG-48-PoE

,

USW-Pro-XG-24-PoE

,

USW-WAN-RJ45

,

UNAS-Pro

,

USW-Flex

,

USW-Flex-3

,

USW-Ultra-60W

,

UX7

,

USW-24

,

UNAS-2-B

,

UNAS-2-W

,

USW-Ultra

,

USW-EnterpriseXG-24

,

USW-Lite-16-POE

,

USW-Flex-2.5G-8-PoE

,

USW-Enterprise-8-PoE
