Ubiquiti Connects to in-elevator readers with PoE to authori

Connects to in-elevator readers with PoE to authorize floor selection. Supports up to 18 floors with digital inputs for elevator car status and emergency.



(1) Elevator Hub





(1) G2 Reader





(2) 2-wire PoE extenders





(10) Access Cards



Technical Specifications

Overview

In the Box

(1) Elevator Hub

(1) G2 Reader

(2) 2-wire PoE extenders

(10) Access Cards

Elevator Hub

Dimensions

129.3 x 244.7 x 33.6 mm

(5.1 x 9.6 x 1.3")

Maximum User Count

6,000

Power Method

PoE++

UL 294 Power-limited Class 2 PSU

UL 60950-1/62368-1 LPS/PS2 PSU

Weight

537 g (1.2 lb)

Enclosure Material

Polycarbonate

NDAA Compliant

Yes

Mounting Material

Polycarbonate

Networking Interface

(4) 10/100/1000 Base-T

PoE Interface

(1) PoE++ input, 50V DC, 1.2A

(4) PoE+ outputs, 50V DC, 30W per port

(Max 45W aggregated)

Management

(1) 10/100/1000 Base-T

Max. Power Consumption

7W (Without PoE output)

Digital Input

(1) Emergency

(1) Car position (5-bit)

(1) Car status: Up/Down/Stop/Full

(1) Door status: Open/Close

Outputs

(18) Relays

Rating 30V DC/2A

ESD/EMP Protection

Air: ±8kV, contact: ±4kV

LEDs

B/W Learn More

Buttons

(1) Factory-reset

Terminal blocks

Ambient Operating Temperature

-10 to 40° C (14 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing

Certifications

CE, FCC, IC, UL 62368-1, CSA C22.2 No. 62368-1

Software Information

The software version can be checked at https://unifi.ui.com

G2 Reader

Dimensions

93 x 40 x 36.5 mm

(3.7 x 1.6 x 1.4")

NFC Card & Keyfob Access

Yes

Mobile Unlock

Yes

Handwave Request to Exit

Yes

Weatherproofing

IP55

NDAA Compliant

Yes

UL 294 Level

Destructive attack: Level I

Line security: Level I

Endurance: Level I

Standby power: Level I

Weight

82 g (2.9 oz)

Enclosure Material

Polycarbonate, glass

Mount Material

Aluminum alloy

Mounting

In-wall, gang box (Included)

Junction box (Optional)

Indoor and Outdoor Use

Yes

Ambient Operating Temperature

-30 to 45° C (-22 to 113° F)

Ambient Operating Humidity

5 to 90% noncondensing

Networking Interface

(1) 10/100 MbE RJ45 port

Connectivity

BLE 4.1

NFC

Power Method

PoE

UL 294 Power-limited Class 2 PSU

UL 60950-1/62368-1 LPS/PS2 PSU

Max. Power Consumption

5W

Supported Voltage Range

48V DC

ESD/EMP Protection

Air: ±15kV, contact: ±8kV

Sensors

Proximity sensor

Speaker

(1) Yes, 0.7W

LEDs

R/G/B/W Learn More

Button

(1) Factory-reset

NFC Read Range

< 30 mm (1.18'')

NFC Frequency

13.56 MHz

NFC Technology

ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)

MIFARE Classic / MIFARE DESFIRE

Sony FeliCa™ (ID only)

NFC Forum tags T1T, T2T, T3T, T4T and T5T

PoE Cabling Requirements

Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.

The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm2 ) for patch cords; 24 AWG (0.21 mm2 ) for horizontal or riser cable.

UL 294 Statement

Compliance with IEEE 802.3 specifications was not verified as part of UL 294.

The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.

CAN/ULC-60839-11-1 Grade

Grade assignment: I

Certifications

CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

Document number, and issue date and/or revision level

UA-G2/UA-G2-Black, V02

Software Information

The software version can be checked at https://unifi.ui.com

Access Card

Dimensions

85.6 x 53.98 x 0.84 mm

(3.37 x 2.13 x 0.03")

Weight

5 g (0.18 oz)

Format

ISO 7810 ID-1

NFC Frequency

13.56 MHz

NFC Technology

ISO/IEC 14443 Type A

MIFARE DESFire

UniFi Access Proprietary Security Protocol

NDAA Compliant

Yes

Wire PoE Extenders

Model

UACC-Extender-2Wire-PoE-Tx/Rx

Dimensions

40 x 105 x 25 mm

(1.6 x 4.1 x 1")

Weight

PoE in: 77 g (2.7 oz)

PoE out: 79 g (2.8 oz)

Enclosure Material

Polycarbonate

Mounting Material

Polycarbonate

NDAA Compliant

Yes

Networking Interface

(1) 10/100 MbE

(1) Homeplug AV

PoE Interface

PoE input: (1) PoE++, 50V DC, Max. 1.2A

PoE output: (1) PoE+, 48V DC, 0.72A

Management

(1) 10/100 MbE

Power Method

PoE++

Max. Power Consumption

3W (Without PoE output)

ESD/EMP Protection

Air: ±8kV, contact: ±4kV

LEDs

White

Ambient Operating Temperature

-10 to 40° C (14 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing

Certifications

CE, FCC, IC
