Zyxel NWA55BE BE5100, 2x2 MU-MIMO, Smart Mesh, Outdoor IP55,

Vonkajšia WiFi 7 je teraz inteligentnejšia. Uvažujete o prechode na WiFi 7 pre vašu vonkajšiu sieť? Zyxel NWA55BE je ideálnym riešením. Router BE5100 (2,4 GHz: 2x2:2, 5 GHz: 2x2:2) je poháňaný štvorjadrovým procesorom Qualcomm a ponúka rýchlosť WiFi 7 až 5,1 Gb/s pre výkon na podnikovej úrovni. Jeho 2,5 GbE port zaisťuje cenovo výhodný a vysokorýchlostný upgrade, ktorý funguje s vašou existujúcou zostavou.



Wireless

Standard



IEEE802.11 be/ax/ac/n/g/b/a



MIMO



MU-MIMO



Wireless speed



2.4GHz: 688Mbps



5GHz: 4324Mbps



Frequency band



2.4GHz:



USA (FCC): 2.412 to 2.462 GHz



Europe (ETSI): 2.412 to 2.472 GHz





5GHz:



USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz



European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz



Bandwidth



20-, 40- ,80-, 160- and 240-MHz



Conducted typical transmit output power*1



US (2.4GHz/5GHz):



25/26dBm





EU (2.4GHz/5GHz):



16/26dBm



RF Design

Antenna type



2 detachable 2.4/5GHz external antenna



Antenna gain



2.4GHz:



2dBi, 2x2:2SS





5GHz:



3dBi, 2x2:2SS



Minimum receive sensitivity



Min. Rx sensitivity up to -99 dBm



WLAN Feature

Band steering



Yes



WDS/Smart Mesh*2



Yes



Wireless Bridge



Yes



Fast roaming



Pre-authentication, PMK caching and 802.11r/k/v



DCS



Yes



Load balancing



No



Advanced cellular coexistence



Yes



Security

Encryption



WEP



WPA



WPA2



WPA3



Authentication



IEEE 802.1X



RADIUS authentication



Access management



L2-isolation



MAC filtering



Rogue AP detection



Networking

IPv6



Yes



VLANs



Yes



WMM



Yes



U-APSD



Yes



Management

Operating mode



Cloud managed



Standalone



ZON Utility



Discovery of Zyxel switches, APs and gateways



Centralized and batch configurations:



IP configuration



IP renew



Device reboot



Device locating



Web GUI access



Firmware upgrade



Password configuration



Web UI/CLI



Yes



SNMP



No



Physical Specifications

Item



Dimensions (WxDxH)(mm/in.)

308 x 136.4 x 49.6 / 12.13 x 5.37 x 1.95



Weight (g/lb.)

575.6 / 1.27



Packing



Dimensions (WxDxH)(mm/in.)

221 x 188 x 59 / 8.70 x 7.40 x 2.32



Weight (g/lb.)

984.5 / 2.17



Included accessories



PoE injector



Mounting screws



MTBF (hr)



631,165



Physical Interfaces

Ethernet port



1 x 1/2.5GbE LAN



Power



PoE (802.3at): power draw 24W



PoE modes



IEEE 802.3af: Not supported



IEEE 802.3at: Unrestricted



IEEE 802.3bt: Unrestricted



Environmental Specifications

Weather Protection



IP55



Operating



Temperature

-25°C to 65°C / -13°F to 149°F



Humidity

10% to 90% (non-condensing)



Storage



Temperature

-40°C to 70°C / -40°F to 158°F



Humidity

10% to 90% (non-condensing)



Certifications

Radio



FCC Part 15C



FCC Part 15E



FCC Part 2.1091



ETSI EN 300 328



EN 301 893



Draft EN 303 687



EN 50385



EN 50665



EN IEC 62311



LP0002



EMC



FCC Part 15B



EN 301 489-1



EN 301 489-17



EN55032



EN55035



EN61000-3-2/-3



EN60601-1-2



BSMI CNS15936



Safety



EN 62368-1



IEC 62368-1



BSMI CNS15598-1



All specifications are subject to change without notice.
