MIKROTIK ROSE Data Server (RouterOS L6)

20 U.2 NVMe storage slots – Ultra-fast, high-density storage for demanding workloads.

100G high-speed networking – 2× 100G QSFP28 ports, 4× 25G SFP28 ports, 4× 10G SFP+ ports, 2× 10G Ethernet ports, and an extra SFF-8644 interface for flexible connectivity.

16-core 2 GHz ARM CPU + 32GB DDR4 RAM – High-performance processing for networking, storage, and virtualization.

Massive energy savings – Cut power consumption and heat output while maintaining high performance – an eco-friendly solution for data-heavy environments.

Runs RouterOS – The most flexible, modular networking OS. Supports advanced storage capabilities, including exporting block devices over NVMe-TCP, encryption layers, and modular storage configurations for scalable infrastructure. No subscriptions. No paywalls.

Container-ready – Run MinIO, Nextcloud, Shinobi, Frigate, and other OCI compliant containers with ease. We’ve added two USB ports for additional devices and further adaptability.

Includes dual hot-swappable power supplies – Ensuring uninterrupted operation and quick replacement without unnecessary downtime.



Specifications

Details

Product code RDS2216-2XG-4S+4XS-2XQ

Architecture ARM 64bit

CPU AL73400

CPU core count 16

CPU nominal frequency 2000 MHz

Switch chip model 98DX4310

RouterOS license 6

Operating System RouterOS v7 (Special ROSE edition)

Size of RAM 32 GB

Storage size 128 MB

Storage type NAND

MTBF Approximately 200'000 hours at 25C

Tested ambient temperature -20°C to 50°C

IPsec hardware acceleration Yes



Powering

Details

Number of AC inputs 2

AC input range 100-240

Frequency (Hz) 50-60

Max power consumption 286 W

Max power consumption without attachments 105 W

Cooling type 10 fans



Ethernet

Details

10/100/1000 Ethernet ports 1

Number of 1G/2.5G/5G/10G Ethernet ports 2



Fiber

Details

SFP+ ports 4

Number of 25G SFP28 ports 4

Number of 100G QSFP28 ports 2



Peripherals

Details

Serial console port RJ45

Number of USB ports 2

USB Power Reset Yes

USB slot type USB 3.0 type A

Max USB current (A) 1

Number of M.2 slots 2



Other

Details

CPU temperature monitor Yes

PCB temperature monitor Yes

Voltage Monitor Yes

Mode button Yes



Certification & Approvals

Details

Certification CE, EAC, ROHS

IP 20
