MIKROTIK Chateau PRO ax with RouterOS L6 license, Internatio

Specifications

Details

Product code H53UiG-5HaxQ2HaxQ

Architecture ARM 64bit

CPU IPQ-8072A

CPU core count 4

CPU nominal frequency 2208 MHz

Switch chip model IPQ-8072

RouterOS license 6

Operating System RouterOS v7

Size of RAM 1 GB

Storage size 128 MB

Storage type NAND

MTBF Approximately 200'000 hours at 25C

Tested ambient temperature -40°C to 70°C



Wireless capabilities

Details

Wireless 2.4 GHz Max data rate 1148 Mbit/s

Wireless 2.4 GHz number of chains 4

Wireless 2.4 GHz standards 802.11b/g/n/ax

Antenna gain dBi for 2.4 GHz 5

Wireless 2.4 GHz chip model QCN-5024

Wireless 2.4 GHz generation Wi-Fi 6

Wireless 5 GHz Max data rate 2400 Mbit/s

Wireless 5 GHz number of chains 4

Wireless 5 GHz standards 802.11a/n/ac/ax

Antenna gain dBi for 5 GHz 6

Wireless 5 GHz chip model QCN-5054

Wireless 5 GHz generation Wi-Fi 6

WiFi speed AX3600



Ethernet

Details

10/100/1000 Ethernet ports 5

Number of 1G Ethernet ports with PoE-out 1



Peripherals

Details

Number of USB ports 1

USB Power Reset Yes

USB slot type USB 3.0 type A

Max USB current (A) 1.5



Powering

Details

Number of DC inputs 1 (DC jack)

DC jack input Voltage 18-57 V

Max power consumption 55 W

Max power consumption without attachments 18 W

Cooling type Passive

PoE-out

Details

PoE-out ports Ether5

PoE out Passive PoE up to 57V

Max out per port output (input 18-30 V) 600 mA

Max out per port output (input 30-57 V) 500 mA

Max total out (A) 0.600 A

Total output current 0.600

Total output power 22.8



Certification & Approvals

Details

Certification CE, FCC, IC, EAC, ROHS

IP 20



Other

Details

CPU temperature monitor Yes

PCB temperature monitor Yes

Voltage Monitor Yes

Mode button Yes
