ASUS TUF RX9070 OC GAMING 16GB/256-bit GDDR6 HDMI 3xDP
ASUS TUF Gaming Radeon™ RX 9070
Architektúra AMD RDNA™ 4 povýšená o vylepšené chladenie a napájanie, aby bez námahy chrlila snímky v rozlíšení 4K a viac.
Model
TUF-RX9070-O16G-GAMING
Graphic Engine
AMD Radeon™ RX 9070
Engine Clock
OC mode(GPU Tweak III): up to 2670 MHz (Boost Clock)/up to 2190 MHz (Game Clock)
Default mode: up to 2650 MHz (Boost Clock)/up to 2170MHz (Game Clock)
Memory Speed
20 Gbps?
Interface
Yes x 1 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1a)
HDCP Support Yes (2.3)
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR6
Stream Processors
3584
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x TUF certificate of Reliability
1 x TUF Gaming Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x TUF Fridge Magnet
1 x Thank you card
1 x Speedsetup Manual
Software
ASUS GPU Tweak III & Drivers: please download all software from the support site.
Dimensions
330 x 140 x 62.5 mm
Recommended PSU
750W
Power Connectors
2 x 8-pin
Slot
3.125 Slot
AURA SYNC
RGB
Note
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
* All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products.
* ‘Game Clock’ is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* ‘Boost Clock’ is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Stránky o produkte:
https://www.asus.com/motherboards-components/graphics-cards/tuf-gaming/tuf-rx9070-o16g-gaming/
